Horizontal Boiler Feed Pump
Introduction
Horizontal Boiler Feed Pump
Alpha Global manufactures and supplies Self Priming Centrifugal Multi-stage Pumps, also known as High Pressure/High Head Pumps. These are specifically used as Boiler Feed Pumps to pump and feed water into steam boilers. This water can be a fresh supply or returning condensate that is a byproduct of steam generated by the evaporator.
Our Range of
Horizontal Boiler Feed Pump
These horizontal multi-stage pumps feature a centrifugal close-vein impeller. The stages are sealed against each other with ‘O’ Rings and are clamped together by tie rods. The suction section is located closer to the coupling, with the release section on the opposite side. They have a heavy-duty ball bearing that can handle thrust loads in either direction and are lubricated with grease for a longer life.
Technical Specifications
| Parameter | Specification |
| Capacity | Up to 18 m³/hr |
| Head | Up to 350 meters |
| Discharge Size | 25 mm to 50 mm |
| Temperature | Up to 140°C |
| Pressure | Up to 28.8 kg/cm² |
| Suction Lift | Up to 7 meters |
| Speed | Up to 2800 RPM |
Why Choose
Alpha Global's Horizontal Boiler Feed Pump ?
High Pressure/Head
A specific type of High Pressure High Head Pump used to pump and feed water into a steam boiler.
Multi-Stage Construction
Horizontal multistage pump where stages are sealed by 'O' Rings and clamped together by tie rods.
Centrifugal Impeller
Uses a centrifugal close vein impeller.
Heavy-Duty Bearings
Incorporates heavy duty metal roller bearings that can convey push stack on either direction.
Lubrication
Features Grease greased up bearing for longer life.
Self-Priming Capability
These pumps also feature self-priming capabilities.
Configuration
Available as bare shaft type pumps.
Applications of
Horizontal Boiler Feed Pump
Alpha Global's Vacuum Pumps (including Oil Sealed and Water Ring types) are utilized across a wide range of industries for processes that require rough, medium, or high vacuum generation.
- Transfer of liquid containing vapor air or gas.
- Boiler feed, marine, refrigeration, fuel oil
- Power plant
- High pressure testing
- Hilly area village
- Sprinkles irrigation
- Industrial clear water
- Condensate water transfer.
- Condensate water transfer.
