Vertical Centrifugal & Sump Pump
Introduction
Vertical Centrifugal & Sump Pump Manufacturer
Alpha Global produces and supplies vertical centrifugal and sump pumps. These pumps are ideal for installations where space is a critical factor or for handling liquids that are difficult to lift due to their nature, such as high temperature or corrosiveness. They are designed for continuous or intermittent service, and can handle both corrosive and ultra-pure chemicals without the risk of corrosion or contamination.
Our Range of
Vertical Centrifugal & Sump Pump
Alpha Global’s vertical centrifugal sump pumps are available in various materials of construction, including steel, cast iron, stainless steel, PP, and PVDF. They can be configured in conventional or tailor-made designs to meet specific application needs. The pumps can also be supplied with additional features such as a suction extension with a float switch or a duplex pumping station with a float switch for automatic on/off functionality.
Technical Specifications| Feature | Technical Details |
|---|---|
| Pump Type | Vertical Centrifugal Sump Pump |
| Flow Rate | Up to 50 m³/hr (Higher capacities on request) |
| Maximum Head | Up to 120 Meters |
| Pump Length | 1 Foot to 12 Feet |
| Maximum Temperature | 110°C (Standard) / 200°C (High Temperature Models) |
| Materials (MOC) | SS, Cast Iron, Polypropylene (PP), PVDF, Steel |
| Configurations | Simplex / Duplex with Auto Float Switch |
Why Choose
Alpha Global's Vertical Centrifugal & Sump Pumps ?
Space Efficiency
The vertical design is ideal for installations where saving of Space is an important factor.
Corrosion & Purity Handling
Designed for liquids of highly corrosive nature or where no adherence of product or zero metallic contamination is a must (e.g., ultra-pure chemicals).
High-Temperature Service
Capable of handling maximum working temperatures up to 110 oC / 200 oC.
Wide Material Options
Available in various Materials of Construction (M.O.C) including Steel, Cast Iron, SS, PP, and PVDF.
Customizable Length & Capacity
Pump lengths are available from 1' to 12' with flow rates up to 50M3/Hr or 120 meter head. Multistage pumps are also available on request
Continuous/ Intermittent Service
Equally ideal for both continuous or intermittent service.
Tailor-Made Configurations
Available in conventional or tailor-made configurations, including models with a suction extension, float switch, or duplex pumping station for Auto On/Off.
Applications of
Vertical Centrifugal & Sump Pump
The Vertical Centrifugal Sump Pump is a type of centrifugal pump with a vertical shaft design where the pumping end (casing and impeller) is submerged in the fluid (sump, pit, or tank), while the motor assembly remains dry and above the fluid level. This configuration is essential for applications where space is limited, where the liquid is difficult to lift, or where no metallic contamination is acceptable.
-
Pollution Control.
-
Filtration systems.
-
Transferring Corrosive Chemicals.
-
Handling Slurries.
-
Use in Effluent Treatment Plants (ETP) and for Industrial Water Transfer
-
Pumping liquids of highly corrosive nature or where zero metallic contamination is necessary.
-
Suitable for High Temperature Services (up to 110 oC/200 oC).
-
Applications in Chemical, Fertilizers, Refineries, Dyes & Intermediate Industries (derived from the similar applications of PP/PVDF pumps).
Watch Our Product Video
Centrifugal Sump Pumps
What is the maximum depth or length available for your sump pumps?
Alpha Global provides vertical sump pumps with customizable lengths ranging from 1 foot to 12 feet, allowing them to be used in deep industrial pits and collection tanks.
Can these pumps handle hot chemicals and acids?
Yes, our vertical pumps are available in high-temperature models capable of handling fluids up to 200°C. We offer various Materials of Construction (MOC) like PP, PVDF, and SS-316 for high chemical resistance.
Do vertical centrifugal pumps require priming?
Since the pump casing and impeller are fully submerged in the fluid within the pit or tank, there is no need for priming, making them highly reliable for intermittent and automatic operations.
What is the benefit of a duplex pumping station configuration?
A duplex pumping station features two pumps with an automatic float switch system. This provides redundancy and automatic operation (Auto On/Off) based on liquid levels, which is essential for ETP and pollution control.
